TN856 CI-IP-223 Telex (Vega) IP Network Remote Adapter
MT-3/4 Radio Systems
TECHNICAL NOTES
Page 1 of 4
LMRSALES@CODANCOMMS.COM
CODANCOMMS.COMTECHNICAL NOTE:
TN856, REV 7-0-0, © Aug 2016
CANADA/US +1 250 382 8268 | TOLL FREE +1 800 664 4066
The Telex IP-223 IP Network remote adapter provides a reliable means of remotely controlling up to two Codan
base stations. The adapter can be used in conjunction with Telex model C-6200, C-Soft, IP-1616, IP-2002 consoles.
The IP-223 is interconnected to the distant remote control console(s) by means of any available Wide Area Network
(WAN) or Local Area Network (LAN) connection.
The Telex CI-IP-223 is capable of operating in several distinct modes:
Local: The radio is connected to the CI-IP-223 directly using a similar connection pin-out as the CI-DSP-223 and is
controlled by Telex VoIP consoles. This mode supports direct serial control of several radio models.
Tone: The CI-IP-223 decodes Ethernet traffi c from Telex VoIP consoles and encodes industry standard tones for
control of existing tone remote adapters. This allows a migration path to VoIP communications and keeps legacy
equipment.
Console: The CI-IP-223 decodes industry standard tones from existing legacy consoles and converts it to Ethernet
traffi c to another CI-IP-223 that regenerates the industry standard tones for control of existing tone remote adapters.
Phone: Using the PIB223, a line on the CI-IP-223 is used to connect to a standard PSTN phone service.
Smart Repeater: In this mode, the CI-IP-223 can be made to link two repeaters together. The CI-IP-223’s are
eff ectively back-to-back on the network.
The Telex IP-223 Network remote adapter provides the following features:
• 2X16 LCD backlit Display
• PTT, Monitor and Power LED indications
• PTT, Monitor, F1 and F2 Relays (programmable to any function tone or Revert to F1)
• Two PTT modes and three monitor modes
• Eight selectable PTT frequencies
• Seven digital outputs for channel selection, completely programmable per function tone
• CTCSS generation (64 frequencies)
• Hardware and software gain control
• Local handset port for monitoring activity and transmission back to base or to radio
• Front panel test points and level set potentiometers
• RS-232C port on rear for initial confi guration and direct radio control
• Single function tone recognition (16 function tones)
• Automatic Gain Control
• Function tone lock-out
• RX Audio Squelch
• Crosspatch capability
• ANI Over the Air - Decode and Display
