Coffee Queen A-2 - Electrical Schematics; A-2 Electrical Schematic

FILTERBREW & SERVING CONCEPT
21
ELECTRICAL SCHEMATICS
A-2
MIC 1
MIC 2
VENT
AUT
ELH
230
MAN
VENT
230
ELH
230
UT1
IN6
UT3
UT4
IN2
A1
A1
Heating Plate
A2
A2
Heating Plate
Rocket Switch Double
Brew Element
Main Socket
Inlet Valve 1.8L
Micro Switch
PCB Original A
IN5
67 4
14
Black
Black
Black
Black
Black
Black
Black
Blue
Black
Blue
Blue
Blue
Blue
Yellow/Green
Yellow/Green
Blue
