Coffee Queen A-2 - Single Cater Electrical Schematic

FILTERBREW & SERVING CONCEPT
27
High Limit
Switch
Element
PCB
NTC
Level
Sensor
Main Socket
Brew Lamp
Solid State
Rocket Switch
Inlet
Tank GND
1
2 3
4 5
6
Black Black Black
Black
Black
Black
Red
Black
Black
Black
Green Yellow
Black Blue
Black
Black
Black
Blue
Blue
Blue
Black
Blue
Blue
Green Yellow
Blue
ELECTRICAL SCHEMATICS
Single Cater
Note:
- Thick wire ≥ 100V
- Thin wire ≤ 24V
