Coffee Queen A-2 - Tower 3 x400-500 VAC+Ground Electrical Schematic

FILTERBREW & SERVING CONCEPT
31
Tower 3x400-500VAC+Ground
ELECTRICAL SCHEMATICS
GND
Zero N 230V
NTC
Inlet
Relay
L1
RST
L2 L3
L1
R
SL2
Tank GND
R-S S-TT-R
PCB
Outlet-2Outlet-1
Switch
Fuse
High limit switch
1
2 3
4
5
6
EL-1
Solid state-1Solid state-2Solid state-3
EL-2 EL-3
400-500V
400-500V
400-500V
Transformer 400-500VAC
