Coffee Queen A-2 - Spare Parts List

FILTERBREW & SERVING CONCEPT
59
EXPLODED VIEW
To w e r
Spare parts list
POS. PCS Part No. Description
1
4 1102122 End cover
2 2 1103302 Serving station 5L
3 1 1305011 OH bulb holder
4 2 1561028 Silicon outlet tube
5 2 1031801 Spray nozzle Tower
6 6 1206503 Fiber washer
7 1 1601312 Element 3000W
8 1 711000 NTC thermistor
9 2 1561010 Seal for outlet valve
10 1 1205302 Sensor short (55mm)
11 1 1461008 Spring washer M3
12 1 1401101-01 Nut M3
13 2 1205301 Sensor long (90mm)
14 2 1605362 Double seal level sensor
15 1 1206586 Gasket tank tower
16 1 220220 High limit switch
17 10 140225 Tank lid screw M4x12mm
18 1 1203526 Tank Tower complete
19 2 160230 Solenoid valve oulet 230V
20 5 140330 Clamp 13.3mm
21
Sale in M
150501 Silicon hose 8x12mm
22 5 140339 Clip for hose 16.4mm
23 2 1403400 Pp plug for drainage hose
24 1 1206123 Non return valve
25 2 1605361 Seal for NTC
26 1 1031502 Tube for overflow
27 1 160351 Connecter PA80 FF
28 3 1605361 Seal for solid state
29 3 1604203/1604201 Solid state 25A
29 3 1604204 Solid state 50A
30 2 1104330 Drip cup
31 1 1608017 Power switch (black)
32 6 1402163 Screw M4X8mm
33 1 1505076 Rubber Plug, 10mm black
34 1 1802120 Connection faucet short
35 1 120200-02 Faucet metal black top
36 1 1031642 Electronic unit PCB Tower
37 1 1603856 Membrane switch, Tower
37 1 1603859 Membrane switch, Single Tower
38 4 120316 Adjustable foot
39 1 1602231 Relay 230V VAC
40 1 160429-02 Fuse automatic
41 1 1605241 Power cord 3-phase 5x2.5mm(1.8m)
42 1 1605651 PG complete (PG16)
43 1 1206603 Gasket DIA23.5mm x 15mm D3mm
44 1 1206604 Gasket DIA18mm x 9mm D2mm
45 1 2760094 Gasket set for inlet hose
46 2 1102131 Brewbasket 5L
47 1 1505042 Inlet hose 3/4”-1/2”
48 1 120634 Valve single 5L/min
49 1 1604393 Electronic filter
50 1 160538-03 plug for water outlet
