FILTERBREW & SERVING CONCEPT
37
EXPLODED VIEW
A-2
Spare parts list
POS. PCS Part No. Description
1 1 120433 Lid, Glass decanter
2 2 110001 Decanter CQ glass
3 1 1102016 Brew basket 1.8L 90 mm
4 2 120811 (230V) Warming plate 230V/95W
4 2 1208121 (110V) Warming plate 110V/95W
5 1 160101 Heat coil 95W
6 1 1204014 Microswitch holder
7 1 1505041 Hot water hose 1.8L
8 1 1204016 Spray nozzle for water tank
9 2 1402150 Screw T20,M4X8mm
10 1 120422 Air inlet plastic 1.8L
11 1 1204012 Lid of tank original
12 1 1204013 Strainer original
13 1 1204015 Water tank complete 1.8L
14 1 160821 (230V) Micro switch tank 1.8L
14 1 1608221 (110V) Micro switch 125V
15 1 1561036 Drainage hose 1.8L
16 1 1505022 Inlet hose 400mm
17 1 1206123 Non return valve 1.8L
18 1 120620-01 (230V) Valve inlet single 1.8L
18 1 120617 (110V) Inlet coil 110V
19 1 160212-03 Over heating protection
20 1 1205101 (230V) Brewing element 230V/2200W
20 1 120505 (110V) Brewing element 110V/1600W
21 1 140339 Clip for hose 16.4mm
22 1 1505021 Silicon hose cold W 1.8L
23 1 1031640 (230V) Electronic unit PCB Original
23 1 1031643 (110V) Electronic unit PCB Original 110V
24 4 120320 Rubber feet V2
25 1 1402163 Screw M4X8mm
26 1 1505063 Bottom rubber TPE
27 1 160802-04 Rocker switch double
28 1 160570 Power cord inlet/Main socket
29 1 1603854 Membran switch origi A
30 1 160565 Main supply cable / Europe
31 1 1505042 Inlet hose 3/4”-1/2”
32 1 1264161 Gasket DIA23.5mm x 15mm D3mm
33 1 1264160 Gasket DIA18mm x 9mm D2mm
34 1 2760094 Gasket set for inlet hose
