Coffee Queen A-2 - Page 39

FILTERBREW & SERVING CONCEPT
39
EXPLODED VIEW
M-2
POS. PCS Part No. Description
1 1 120433 Lid, Glass decanter
2 2 110001 Decanter glass
3 1 1102016 Brew basket 1.8L 90 mm
4 2 120811 (230V) Warming plate 230V/95W
4 2 1208121 (110V) Warming plate 110V/95W
5 1 160101 Heat coil 95W
6 1 1505041 Silicon hose hot 1.8L
7 1 1204016 Spray nozzle for water tank
8 1 1402150 Screw T20 M 4x8mm
9 1 120422 Air inlet plastic 1.8L
10 1 1204012 Lid of tank original
11 1 1204013 Strainer original
12 1 1204015 Water tank complete 1.8L
13 1 160821 (230V) Micro switch tank 1.8L
13 1 1608221 (110V) Microswitch 125V
14 1 1204014 Microswitch holder
15 1 1505062 Overflow hose
16 1 1206123 Non return valve
17 1 160212-03 Over heating protection
18 1 1205101 (230V) Brewing element 230V/2200W
18 1 120505 (110V) Brewing element 110V/1600W
19 4 140339 Clip for hose 16.4mm
20 1 1031503 Silicon hose cold complete
21 1 160565 Main supply cable / Europe
22 1 160570 Power cord inlet/Main socket
23 1 160804-04 Brewing lamp
24 1 160802-04 Rocker switch double
25 1 1505063 Rubber bottom TPE
26 4 120320 Rubber feet V2
27 4 1402163 Screw M4x8
Spare parts list
