FILTERBREW & SERVING CONCEPT
41
EXPLODED VIEW
DA-4
Spare parts list
POS. PCS Part No. Description
1 1 120433 Decanter lid
2 4 110001 Decanter CQ glass
3 2 1204012 Lid of tank original
4 2 1204013 Strainer
5 2 1102016 Brew basket 1.8L 90 mm
6 2 1204015 Water tank complete 1.8L
7 2 120422 Air inlet plastic 1.8L
8 1 1402150 Screw T20,M4X8
9 2 1031503 Silicon hose cold complete
10 2 1505041 Silicon hose hot 1.8L
11 2 160212-03 Over heating protection
12 1 150501 Silicone tube 8x12mm
13 1 1505042 Inlet hose 3/4”-1/2”
14 1 1206603 Gasket DIA23.5mm x 15mm D3mm
15 1 1206604 Gasket DIA18mm x 9mm D2mm
16 1 2760094 Gasket set for inlet hose
17 4 140339 Clip for hose 16.4mm
18 2 1205101 Brewing elemnet 230V/2200W
19 1 120621-01 Inlet valve 0.95x2L Double
20 2 1505062 Overflow tube
21 2 1206123 Non return valve
22 1 1605651 PG complete (PG16)
23 1 160549 Connector fv122
24 2 1204016 Spray nozzle for water tank
25 6 160536 Gasket rubber NBR(Rubber TRP 30.0)
26 1 1505063 Rubber bottom TPE
27 4 120320 Rubber feet V2
28 4 1402163 Screw M4x8
29 4 120811 Warning plate 230V/95W
30 1 160101 Heat coil 95W
31 2 1031640 Electronic unit PCB Orginal
32 2 160802-04 Rocker switch double
33 2 1603854 Membran switch origi A
34 2 160821 Micro switch tank 1.8L
35 1 1204014 Microswitch holder
36 1 1605210 Power cable 4 x 1.5mm
