FILTERBREW & SERVING CONCEPT
43
EXPLODED VIEW
DM-4
Spare parts list
POS. PCS Part No. Description
1 1 120433 Decanter lid
2 4 110001 Decanter CQ glass
3 2 1204012 Lid of tank original
4 2 1204013 Strainer
5 2 1102016 Brew basket 1.8L 90 mm
6 2 1204015 Water tank complete 1.8L
7 2 1505041 Silicon hose hot 1.8L
8 2 120422 Air inlet plastic 1.8L
9 12 1402150 Screw T20,M4X8
10 2 160212-03 Over heating protection
11 1 1605651 PG complete (PG16)
12 1 1605210 Power cable 4 x 1.5mm
13 2 1031503 Silicon hose cold complete
14 4 140339 Clip for hose 16.4mm
15 2 1205101 Brewing elemnet 230V/2200W
16 2 1505062 Overflow tube
17 1 1206123 Non return valve
18 1 160549 Connector fv122
19 2 1204016 Spray nozzle for water tank
20 6 160536 Gasket rubber NBR(Rubber Trp 30.0)
21 2 1204014 Microswitch holder
22 2 160821 Micro switch tank 1.8L
23 2 1505063 Bottom cover rubber
24 4 120320 Rubber feet V2
25 4 1402163 Screw M4x8
26 4 120811 Warming plate 230V/95W
27 1 160101 Heat coil 95W
28 1 1603855 Overlay original M
29 1 160804-04 Brewing lamp
30 1 160802-04 Rocker switch double
