FILTERBREW & SERVING CONCEPT
47
EXPLODED VIEW
Mega Gold M
Spare parts list
POS. PCS Part No. Description
1 1 1204012 Lid
2 1 1204013 Strainer
3 1 1204015 Water tank complete 1.8L
4 1 1505062 Overflow hose 1.8L
5 1 160212-03 Over heating protection
6 1 1205101 (230V) Brewing element 230V/2200W
6 1 120505 (110V) Brewing element 110V/1600W
7 1 1031503 Silicon hose cold complete
8 1 1102016 Brew basket 1.8L
9 1 1402150 Screw T20, M4X8mm
10 1 1204016 Spray nozzle for water tank
11 1 1505041 Siliocn hose hot W 1.8L
12 1 1204014 Microswitch holder
13 1 1206123 Non return valve 1.8L
14 1 160821 (230V) Microswitch tank 1.8L
14 1 1608221 (110V) Micro switch 125V
15 4 140339 Clip for hose 16.4mm
16 6 160536 Gasket rubber NBR(Rubber Trp 30.0)
17 1 1603855 Overlay original M
18 1 1505063 Bottom cover rubber
19 1 160570 Power cord inlet/ Main socket
20 1 160801-04 Rocker switch single
21 1 160804-04 Brewing lamp
22 1 1103303 Serving station 2.5L
23 4 120320 Rubber feet
24 4 1402163 Screw M4x8
25 1 160565 Main supply cable / Europe
