FILTERBREW & SERVING CONCEPT
49
EXPLODED VIEW
Thermos Office
Spare parts list
POS. PCS Part No. Description
1 1 1102016 Brew basket 1.8L 90 mm
2 1 1204012 Lid of tank original
3 1 1204013 Strainer original
4 1 1204015 Water tank complete 1.8L
5 1 160821 (230V) Micro switch tank 1.8L
5 1 1608221 (110V) Micro switch 125V
6 1 1204014 Microswitch holder
7 1 1505062 Over flow hose 1.8L
8 1 1505041 Silicon hose hot 1.8L
9 1 1204016 Spray nozzle for water tank
10 2 1402150 Screw T20,M4X8mm
11 1 120422 Air inlet plastic 1.8L
12 1 160212-03 Over heating protection
13 1 1205101 (230V) Brewing element 230V/2200W
13 1 120505 (110V) Brewing element 110V/1600W
14 4 140339 Clip for hose 16.4mm
15 1 1031503 Silicon hose cold complete
16 1 160565 Main supply cable / Europe
17 1 160570 Power cord inlet / Main socket
18 1 160804-04 Brewing lamp
19 1 160801-4 Rocker switch single
20 1 1103256 Thermos 1.9L
21 1 1505063 Rubber bottom TPE
22 4 120320 Rubber feet V2
23 4 1402163 Screw M4x8
