FILTERBREW & SERVING CONCEPT
51
EXPLODED VIEW
Thermos A
Spare parts list
POS. PCS Part No. Description
1 1 1204012 Lid of tank original
2 1 1204013 Strainer original
3 1 1102016 Brew basket 1.8L 90 mm
4 1 1206604 Gasket DIA18mm x 9mm D2mm
5 1 1206603 Gasket DIA23.5mm x 15mm D3mm
6 1 2760094 Gasket set for inlet hose
7 1 1505042 Inlet hose 3/4”-1/2”
8 1 1103184 Thermos 2.2L
9 1 1204015 Water tank complete 1.8L
10 1 160821 (230V) Micro switch tank 1.8L
10 1 1608221 (110V) Micro switch 125V
11 1 1204014 Microswitch holder
12 1 1505062 Overflow hose
13 Sale in M 150501 Silicone tube 8x12mm
14 1 120620-01 (230V) Valve inlet single 1.8L
14 1 120617 (110V) Inlet coil 110V
15 1 1505041 Hot water hose 1.8L
16 1 1204016 Spray nozzle for water tank
17 2 1402150 Screw T20,M4X8mm
18 1 120422 Air inlet plastic 1.8L
19 1 160212-03 Over heating protection
20 1 1205101 (230V) Brewing element 230V/2200W
20 1 120505 (110V) Brewing element 110V/1600W
21 1 140339 Clip for hose 16.4mm
22 1 1031503 Silicon hose cold complete
23 1 1031640 (230V) Electronic unit PCB Original
23 1 1031643 (110V) Electronic unit PCB Original 110V
24 4 120320 Rubber feet V2
25 4 1402163 Screw M4x8
26 1 1505063 Bottom rubber TPE
27 6 160536 Gasket rubber NBR(Rubber Trp 30.0)
28 1 160801-04 Rocker switch single(orange)
29 1 160570 Power cord inlet/Main socket
30 1 1603854 Membran switch Original A
31 1 160565 Main supply cable / Europe
