FILTERBREW & SERVING CONCEPT
61
EXPLODED VIEW
Grinder original
Spare parts list
POS. PCS Part No. Description
1 1 1364001 Finger Protection
2 1 1608281 Magnet 39x13x6mm
3 1 1364002 Metal Plate for finger protection
4 1 1105517 Bean Hopper
5 1 1031647 Electronic unit PCB Grinder
6 9 140204 Screw M4x6
7 1 1561004 Sealing Rbbber
8 1 1604752 Grinder EK-21
9 1 1204651 Rubber trp 40
10 1 1605652 Power cable fixed 16A 250V
11 1 1264027 Nylon washer 8mm
12 1 1461038 Screw M4x6 with step
13 1 83243641 Silicone flap
14 1 1561003 Outlet tube sealing
15 1 1264009 Nylon base Grinder
16 1 1561002 Base silcon Grinder
17 4 1561005 Nylon Bushing
18 1 1461005 Screw M4x40
19 2 1264013 Nylon Slide Guide
20 1 83257335 Capacitor
21 1 160245 Relay 230V C7-A20
22 1 160247 Chassi adapter
23 1 1505076 Rubber Plug,10mm black
24 1 1608017 Rocker Switch Black
25 1 1603854 Membran switch original
26 1 1608131 Adjustment wheel 20mm
27 1 1608132 Cover lid 20mm
28 1 710553 Adjustment kit
29 1 1461019 Spring link 14cm
30 1 1401901 Screw M4x16
31 1 1402163 Screw M4x8mm
32 1 120320 Rubber Feet
33 1 160351 Connecter PA80 FF
34 1 160246 Socket V-7 relay
