Cognex DataMan 100 - Getting Started; Setting up Your Dataman; Using Your Dataman; Reference Information

ii DataMan 100 Quick Reference Guide DataMan 100 Quick Reference Guide iii
Getting Started
Setting up your DataMan
Connect your DataMan
Using your DataMan
Page 4
Page 8
Page 14
Page 22
Reference Information
Page 27
DataMan 100 Systems • DataMan 100 Accessories •
Product Overview • Mounting
Install DataMan Software • Reading your First Code
• Setting the Focus Position • Field of View • Reading
Distances
USB Connections • RS-232 Connections • Wiring with the
Basic I/O Module • Wiring the Expansion I/O Module
DataMan 100 Trigger types • Trigger Modes • Training •
Training Feedback
DataMan 100 Specications • DataMan 100 Cable Pinout
• Digital Input Wiring Diagrams • Digital Output Wiring
Diagrams • Multi-Port Connections • SensorView Teach
Pendant Support • RS-232 Parameter Codes
1
3
4
5
2
