3 RS-232
4 USB
5 Power plug (24 V, max. 15 W)
6 Alternative power supply connector (24 V, max. 15 W, polarity marked on the
plastic part near the connector)
Recommended wire diameter is 14-18 AWG
7 Ethernet
Base Station status indicators:
l Power: RED = base powered / BLINK = wrong reader in base
l Communication: BLUE = Wireless link / BLINK = Wireless communication
l Cradle connections: GREEN = reader properly inserted / BLINK = cradle USB interface communication
Note:
l DMA-IBASE-BT-01 does not support Ethernet
l DMA-IBASE-BT-02 supports Ethernet
13
Getting Started
