6
Chapter 2: Getting Started
Printhead Assembly (TPH, Shield, Bracket, and LED Array)
Figure 2-8. Printhead Assembly
Components Description
A Printhead
B Bracket
C LED Array
D Shield
Platen and Index Sensor
Figure 2-9. Platen Assembly and Index Sensor
Components Description
A Index Sensor
B Platen
A
B
C
D
A
B
