Pre-Installation Guidelines & Checklist
10
Electrical Service & Supply
The Pelletizer requires a three-phase power supply. The power source must be grounded:
y For machines in the US: use a Solidly Grounded WYE Source.
y For machines outside US: use a TN-S grounding acc. to IEC 60364.
y All phases must be balanced, and voltages must be within ±10%.
The customer is responsible for the electrical installation of the pelletizer. This includes the
power cable and main circuit breaker which meet the specications below. The main circuit
must be suitable for proper lock out / tag out in accordance with international and national
standards and requirements.
Before startup, verify the direction of rotation is the same as indicated on the motor for the
hydraulic pump and on the motor for the oil cooler pump, if applicable.
Electrical Service & Supply PR120H PR350H PR750H
Voltage AC/ Frequency (EU 50Hz) 3 x 400 VAC/50Hz
Voltage AC/ Frequency (US 60 Hz) 3 x 480 VAC/60Hz
Average Power Consumption 4.3 kw (5.8 hp) 5.5 kw (7.4 hp) 11 kw (15 hp)
Rated Current (Imax) 16 Amp 32 Amp 32 Amp
Instrument Process Air Supply
The pelletizer requires instrument air/CO
2
gas at a minimum pressure of 8 bar (116 psi) as the
input to the pressure regulator in the machine.
The customer is responsible for the pneumatic installation of the pelletizer. A valve must be
installed to ensure proper safe lock-out/tag-out of the machine with reference to relevant
machine safety standards.
Instrument Process Air Supply PR120H PR350H PR750H
Compressed Air Quality ISO 8573-1, Minimum class 3
Supply Pressure (MIN-MAX) 8-10 bar (116-145 psi)
Flow minimum (normal liter) 150 l/min (5.3 cfm)
Air Connection at Pelletizer ID 12.7 mm (0.5 in) / 1/2-inch BSP - 1/2-inch NPT
