Coleman DB70 - Description and Part Locations.8

1. Front Wheel
2. Front Brake Drum
3. Front Fender
4. Front Forks/
Shocks
5. Fuel tank cap
6. Fuel tank
7. Seat
8. Rear Fender
9. Rear Wheel
10. Rear sprocket
11. Drive Chain
12. Kick Stand
13. Ignition Key
14. Choke lever
15. Fuel Valve
16. Rear Wheel
17. Mufer
18. Rear Fender
19. Carburetor
20. Spark Plug
21. Foot Brake lever
22. Oil ll plug
23. Rear Mono Shock
24. Rear brake
adjustment
25. Left hand grip
26. Front brake lever
27. Right throttle hand
grip
28. ON/OFF switch
1
2
3
4
5
6
7
8
9
10
12
11
13
14
15
16
17
18
19
20
21
2223
24
25
27
28
26
DESCRIPTIONS AND PART LOCATIONS
