Coleman DB70 - Footbrake Lever; Ignition Key; Choke Lever

Choke Lever (1): If the engine is
cold, the choke can help start the
engine by lifting the choke lever to
the “ON” (up) position. Once engine
has warmed up , place choke lever
to the “OFF” (down) position.
2
Choke Lever
Ignition Key
Ignition Key (2)
Engine can start once the ignition
key is placed in the (on) postion.
Note: Engine stop switch located
on the handlebars also needs to be
placed in the (on) position for the
engine to start.
Foot brake lever
Foot brake lever (1): To activate the
rear brake, depress the foot brake
lever.
1
3
DESCRIPTION AND PART FUNCTIONS
10
