Coleman PCG4B60 - Sound Performance; Electrical Data

5564041-CTG-A-1018
10 Johnson Controls Unitary Products
INDOOR BLOWER SPECIFICATIONS
Model
Motor
HP RPM EFF. SF Frame
24050 1/3 Variable 0.8 1.0 48
24075 1/2 Variable 0.8 1.0 48
30050 1/3 Variable 0.8 1.0 48
30075 1/2 Variable 0.8 1.0 48
36050 1/2 Variable 0.8 1.0 48
36075 1/2 Variable 0.8 1.0 48
36100 3/4 Variable 0.8 1.0 48
42075 3/4 Variable 0.8 1.0 48
42100 3/4 Variable 0.8 1.0 48
48065 3/4 Variable 0.8 1.0 48
48100 3/4 Variable 0.8 1.0 48
48125 3/4 Variable 0.8 1.0 48
60065 1 Variable 0.8 1.0 48
60100 1 Variable 0.8 1.0 48
60125 1 Variable 0.8 1.0 48
SOUND PERFORMANCE
Model
(Tons)
Sound Rating
1
dB (A)
1. Rated in accordance with AHRI Standard 270.
Octave Band Centerline Frequency (Hz)
125 250 500 1000 2000 4000 8000
A36 74 58.5 61.8 65.4 66.5 60.7 54.8 49.8
A42 74 63.5 63.9 62.3 65.0 64.0 54.1 46.6
B48 74 63.5 63.9 62.3 65.0 64.0 54.1 46.6
B60 76 72.3 65.0 63.9 64.0 60.0 55.5 49.0
ELECTRICAL DATA
Model Voltage
Compressor
OD Fan
Motor
Supply
Blower Motor
MCA
1
(Amps)
Max Fuse
2
/
Breaker
3
Size
(Amps)
RLA LRA MCC FLA FLA
36050, 36075 208/230-3-60 10.4 73.0 16.3 1.3 3.8 18.1 25
36100 208/230-3-60 10.4 73.0 16.3 1.3 5.4 18.1 25
42075, 42100 208/230-3-60 13.5 88.0 21.1 1.3 5.4 23.6 35
48065, 48100, 48125 208/230-3-60 13.7 83.1 21.4 1.7 5.4 24.2 35
60065, 60100, 60125 208/230-3-60 16.0 110.0 24.9 1.7 7.0 28.7 40
1. Minimum Circuit Ampacity.
2. Maximum Over Current Protection per standard UL 1995.
3. Fuse or HACR circuit breaker size installed at factory or field installed.
