Coleman PCG4B60 - Airflow Performance; Bottom Duct Application

5564041-CTG-A-1018
Johnson Controls Unitary Products 13
1. Airflow tested with dry coil conditions, without air filters, at 230 volts
2. Applications above 0.8" w.c. external static pressure are not recommended.
3. Brushless DC high efficiency standard ECM blower motor used for all indoor blower assemblies.
4. Minimal variations in airflow performance data results from operating at 208 volts. Data above may be used in those cases.
5. Heating applications tested at 0.50" w.c. esp, and cooling applications tested at 0.30" w.c.esp per standards.
60125
Low (1) 2063 2008 1943 1899 1851 1809 1763 1717 1625
Low/Medium (2) 2130 2084 2032 1983 1927 1951 1860 1815 1725
Medium (3) 2195 2144 2098 2049 2003 1955 1883 1868 1838
Medium/High (4) 2275 2252 2169 2154 2112 2065 1989 1976 1950
High (5) 2445 2388 2306 2293 2235 2178 2129 2077 1973
AIRFLOW PERFORMANCE - SIDE DUCT APPLICATION (Continued)
Model Motor Speed
External Static Pressure (Inches WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 1.0
SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM
AIRFLOW PERFORMANCE - BOTTOM DUCT APPLICATION
Model Motor Speed
External Static Pressure (Inches WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 1.0
SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM
36050
Low (1) 1008 962 916 861 807 757 700 650 550
Low/Medium (2) 1190 1148 1106 1055 1008 955 914 863 761
Medium (3) 1262 1223 1181 1137 1091 1044 994 952 868
Medium/High (4) 1324 1282 1245 1202 1161 1112 1067 1018 920
High (5) 1517 1475 1447 1400 1357 1318 1275 1232 1146
36075
Low (1) 1231 1186 1146 1103 1069 1030 977 912 781
Low/Medium (2) 1270 1225 1189 1140 1098 1046 1008 960 866
Medium (3) 1317 1286 1245 1198 1151 1110 1064 1024 943
Medium/High (4) 1358 1317 1275 1238 1197 1148 1105 1057 961
High (5) 1517 1475 1447 1400 1357 1318 1275 1232 1146
36100
Low (1) 1340 1299 1264 1224 1182 1182 1097 1049 953
Low/Medium (2) 1409 1368 1334 1291 1253 1201 1173 1128 1038
Medium (3) 1527 1492 1470 1419 1385 1343 1299 1250 1152
Medium/High (4) 1663 1585 1594 1601 1521 1480 1440 1400 1320
High (5) 1930 1892 1853 1805 1760 1696 1625 1553 1409
42075
Low (1) 1332 1295 1263 1222 1185 1148 1110 1063 967
Low/Medium (2) 1457 1419 1376 1340 1299 1253 1215 1160 1051
Medium (3) 1451 1412 1371 1339 1296 1257 1211 1165 1072
Medium/High (4) 1568 1524 1491 1464 1425 1383 1345 1296 1200
High (5) 1978 1937 1891 1837 1785 1725 1656 1604 1502
42100
Low (1) 1455 1414 1379 1335 1294 1254 1212 1160 1056
Low/Medium (2) 1566 1532 1492 1455 1416 1372 1333 1280 1174
Medium (3) 1565 1530 1491 1458 1419 1381 1336 1290 1198
Medium/High (4) 1675 1641 1606 1578 1535 1495 1455 1412 1326
High (5) 1946 1909 1863 1815 1771 1721 1654 1595 1477
48065
Low (1) 1032 999 970 938 910 879 843 808 737
Low/Medium (2) 1272 1236 1204 1165 1129 1081 1037 968 829
Medium (3) 1611 1574 1518 1494 1439 1405 1357 1266 1083
Medium/High (4) 1892 1777 1771 1701 1639 1617 1565 1489 1336
High (5) 2131 2058 1998 1949 1892 1840 1788 1728 1608
48100
Low (1) 1598 1548 1502 1454 1410 1362 1307 1251 1139
Low/Medium (2) 1663 1612 1568 1522 1476 1422 1370 1297 1152
Medium (3) 1789 1733 1670 1650 1596 1578 1535 1483 1379
Medium/High (4) 1931 1814 1808 1736 1673 1650 1597 1519 1362
High (5) 2131 2058 1998 1949 1892 1840 1788 1728 1608
Continued on next page.
