Coleman PCG4B60 - Airflow Performance - Side Duct Application

5564041-CTG-A-1018
12 Johnson Controls Unitary Products
AIRFLOW PERFORMANCE - SIDE DUCT APPLICATION
Model Motor Speed
External Static Pressure (Inches WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 1.0
SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM
36050
Low (1) 1003 952 904 851 790 730 674 633 551
Low/Medium (2) 1180 1133 1085 1042 995 942 889 834 724
Medium (3) 1259 1209 1166 1126 1084 1032 980 928 824
Medium/High (4) 1314 1271 1229 1186 1144 1097 1049 998 896
High (5) 1506 1471 1403 1389 1345 1305 1262 1216 1124
36075
Low (1) 1225 1174 1131 1090 1046 993 941 888 782
Low/Medium (2) 1259 1209 1166 1126 1084 1032 980 928 824
Medium (3) 1314 1271 1229 1186 1144 1097 1049 998 896
Medium/High (4) 1348 1306 1259 1222 1179 1133 1086 1036 936
High (5) 1506 1471 1403 1389 1345 1305 1262 1216 1124
36100
Low (1) 1342 1302 1260 1217 1178 1134 1082 1034 938
Low/Medium (2) 1425 1368 1332 1293 1251 1208 1163 1113 1013
Medium (3) 1554 1503 1465 1423 1386 1346 1302 1257 1167
Medium/High (4) 1658 1599 1588 1530 1495 1454 1414 1373 1291
High (5) 1966 1914 1862 1810 1757 1705 1653 1600 1496
42075
Low (1) 1315 1266 1229 1194 1156 1117 1080 1036 948
Low/Medium (2) 1436 1382 1342 1304 1262 1220 1179 1131 1035
Medium (3) 1458 1406 1365 1327 1286 1244 1203 1155 1059
Medium/High (4) 1573 1523 1484 1445 1408 1367 1327 1279 1183
High (5) 1966 1914 1862 1810 1757 1705 1653 1600 1496
42100
Low (1) 1436 1382 1342 1304 1262 1220 1179 1131 1035
Low/Medium (2) 1544 1492 1455 1416 1376 1336 1294 1248 1156
Medium (3) 1573 1523 1484 1445 1408 1367 1327 1279 1183
Medium/High (4) 1681 1640 1599 1557 1517 1478 1436 1393 1307
High (5) 1935 1887 1834 1788 1743 1701 1651 1591 1471
48065
Low (1) 1046 1009 980 946 915 878 844 779 649
Low/Medium (2) 1295 1250 1213 1172 1133 1087 1045 964 802
Medium (3) 1620 1564 1517 1466 1418 1360 1308 1206 1002
Medium/High (4) 1798 1722 1669 1620 1572 1527 1480 1413 1280
High (5) 2146 2085 2025 1960 1872 1862 1798 1735 1609
48100
Low (1) 1620 1564 1517 1466 1418 1360 1308 1206 1002
Low/Medium (2) 1694 1630 1580 1530 1482 1430 1380 1292 1116
Medium (3) 1798 1722 1669 1620 1572 1527 1480 1413 1280
Medium/High (4) 1835 1758 1703 1653 1604 1558 1511 1442 1304
High (5) 2146 2085 2025 1960 1872 1862 1798 1735 1609
48125
Low (1) 1620 1564 1517 1466 1418 1360 1308 1206 1002
Low/Medium (2) 1798 1722 1669 1620 1572 1527 1480 1413 1280
Medium (3) 1922 1863 1804 1754 1724 1658 1612 1559 1453
Medium/High (4) 2001 1952 1890 1839 1820 1742 1696 1651 1561
High (5) 2146 2085 2025 1960 1872 1862 1798 1735 1609
60065
Low (1) 1073 1043 1009 988 963 941 917 892 842
Low/Medium (2) 1329 1292 1250 1223 1192 1165 1136 1105 1043
Medium (3) 2054 1998 1934 1890 1843 1801 1757 1710 1616
Medium/High (4) 2195 2144 2098 2049 2003 1955 1883 1868 1838
High (5) 2445 2388 2306 2293 2235 2178 2129 2077 1973
60100
Low (1) 1730 1682 1628 1592 1552 1517 1479 1439 1359
Low/Medium (2) 1858 1807 1749 1710 1667 1629 1589 1546 1460
Medium (3) 2054 1998 1934 1890 1843 1801 1757 1710 1616
Medium/High (4) 2195 2144 2098 2049 2003 1955 1883 1868 1838
High (5) 2445 2388 2306 2293 2235 2178 2129 2077 1973
Continued on next page.
