PHYSICAL DATA
COMPONENT
MODELS
PCG4A36 PCG4A42 PCG4B48 PCG4B60
NOMINAL TONNAGE 3.0 3.5 4.0 5.0
AHRI Cooling Performance
Gross Capacity @ AHRI A point (MBH) 37.2 43.5 47.7 55.0
AHRI net capacity (MBH) 34.6 41.0 45.5 52.5
EER 11.0 11.0 11.0 11.0
SEER 14.0 14.0 14.0 14.0
Nominal CFM 1200 1400 1600 2000
System power (KW) 3.2 3.8 4.2 4.8
Refrigerant type R410A R410A R410A R410A
Refrigerant charge (lb-oz) 8-8 9-4 11-3 12-0
AHRI Gas Heat Performance
Heating model 50 75 100 75 100 65 100 125 65 100 125
Heat input (K Btu) 50.0 75.0 100.0 75.0 100.0 65.0 100.0 125.0 65.0 100.0 125.0
Heat output (K Btu) 40 60 80 60 80 52 80 100 52 80 100
AFUE% 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0 81.0
No. burners 2 3 4 3 4 2 3 4 2 3 4
No. stages 1 1 1 1 1 1 1 1 1 1 1
Temperature Rise Range (°F) 35-65 40-70 40-70 40-70 40-70
Max. Static Pressure w.c. 0.5 0.5 0.5 0.5
Max. Outlet Air Temp. (°F) 180 180 180 180
Gas piping connection (in.) 1/2 1/2 1/2 1/2
Dimensions (inches)
Length 51-1/4 51-1/4 51-1/4 51-1/4
Width 35-3/4 35-3/4 45-3/4 45-3/4
Height 47 49 49 51
Operating WT. (lbs.) 394 401 405 441 443 460 468 473 477 481 488
Compressors
Type Scroll Scroll Scroll Scroll
Outdoor Coil Data
Face area (Sq. Ft.) 15.1 16.9 19.5 21.5
Rows 2 2 2 2
Fins per inch 22 22 22 22
Tube diameter 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Indoor Coil Data
Face area (Sq. Ft.) 4.6 4.6 6.3 6.3
Rows 3 3 3 3
Fins per inch 16 16 16 16
Tube diameter 3/8 3/8 3/8 3/8
Circuitry Type Interlaced Interlaced Interlaced Interlaced
Refrigerant control TXV TXV TXV TXV
Outdoor Fan Data
Fan diameter (Inch) 24 24 26 26
Type Prop Prop Prop Prop
Drive type Direct Direct Direct Direct
No. speeds 1 1 1 1
Motor HP each 1/4 1/4 1/3 1/3
RPM 850 850 850 850
Nominal total CFM 2400 2400 3200 3200
Direct Drive Indoor Fan Data
Fan Size (Inch) 11 x 10 11 x 10 11 x 10 11 x 10
Type Centrifugal Centrifugal Centrifugal Centrifugal
Motor HP each 1/2 3/4 3/4 3/4 1
RPM 1200 Max 1200 Max 1200 Max 1200 Max
Frame size 48 48 48 48
Filter
Filter Size A A B B
Quantity - Size
Field-supplied external filters must be sized so as not to exceed 300 fpm air velocity through disposable fil-
ters. For internal filter use, a filter rack kit is included with all three phase models. Consult the instructions
supplied with that kit for replacement filter sizes. Filter sizes: A=20x20, B=20x30.
