COOLING PERFORMANCE DATA - 4 TON
PACKAGED UNIT MODEL NO. PCG4B48
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1400 1600 1800
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 50.7 55.0 54.4 59.4 65.3 53.0 56.8 56.1 61.2 67.2 55.4 58.6 57.9 63.1 69.1
S.C. 48.2 44.8 38.3 38.5 30.4 49.3 48.2 41.0 40.7 31.9 50.3 51.5 43.6 42.9 33.4
K.W. 2.48 2.52 2.51 2.54 2.56 2.56 2.59 2.58 2.61 2.62 2.64 2.65 2.64 2.67 2.68
65 / 55
T.C. 48.0 52.0 51.2 57.1 62.8 50.3 53.6 52.9 58.7 64.4 52.5 55.2 54.5 60.3 66.0
S.C. 44.3 43.2 36.7 37.1 29.6 46.3 46.6 39.3 39.4 30.8 48.4 50.0 41.9 41.7 32.1
K.W. 2.76 2.79 2.79 2.81 2.83 2.83 2.85 2.85 2.88 2.89 2.90 2.92 2.91 2.94 2.95
75 / 63
T.C. 45.4 49.0 48.1 54.9 60.3 47.5 50.4 49.6 56.2 61.6 49.6 51.8 51.1 57.5 62.9
S.C. 40.3 41.7 35.0 35.7 28.7 43.4 45.1 37.6 38.1 29.7 46.4 48.4 40.2 40.5 30.8
K.W. 3.04 3.06 3.06 3.08 3.11 3.10 3.12 3.12 3.14 3.17 3.16 3.18 3.18 3.21 3.23
85 / 69
T.C. 42.9 45.4 44.9 51.3 56.4 44.8 46.6 46.1 52.5 57.7 46.7 47.7 47.2 53.6 59.1
S.C. 38.3 39.8 33.2 33.7 27.3 41.4 42.4 35.7 36.3 28.4 44.4 44.9 38.2 38.9 29.4
K.W. 3.41 3.42 3.42 3.44 3.46 3.47 3.49 3.48 3.50 3.53 3.53 3.55 3.54 3.57 3.59
95 / 75
T.C. 40.4 41.8 41.7 47.7 52.4 42.1 42.7 42.6 48.7 53.8 43.9 43.6 43.4 49.7 55.2
S.C. 36.4 38.0 31.4 31.8 25.9 39.4 39.7 33.8 34.5 27.0 42.4 41.4 36.2 37.3 28.1
K.W. 3.79 3.79 3.78 3.80 3.82 3.85 3.85 3.83 3.86 3.89 3.90 3.91 3.89 3.92 3.95
105 / 83
T.C. 36.7 37.6 37.5 43.5 47.8 38.1 38.4 38.0 44.3 48.9 39.5 39.2 38.6 45.1 50.0
S.C. 32.3 34.7 29.7 30.0 23.9 34.3 36.1 31.1 32.6 24.9 36.4 37.4 32.6 35.1 26.0
K.W. 4.30 4.30 4.29 4.32 4.34 4.36 4.36 4.35 4.38 4.41 4.43 4.42 4.41 4.44 4.47
115 / 89
T.C. 33.1 33.6 33.3 39.4 43.4 34.1 34.3 33.6 40.0 44.2 35.2 35.0 33.8 40.6 45.0
S.C. 28.4 31.6 28.0 28.4 21.9 29.4 32.5 28.6 30.7 22.9 30.5 33.5 29.1 33.0 23.9
K.W. 4.80 4.80 4.79 4.83 4.85 4.87 4.86 4.86 4.89 4.91 4.93 4.92 4.92 4.95 4.97
125 / 95
T.C. 29.5 29.5 29.2 35.3 39.0 30.2 30.1 29.2 35.7 39.5 30.9 30.7 29.1 36.1 40.0
S.C. 24.5 28.4 26.4 26.7 19.9 24.5 29.0 26.0 28.8 20.9 24.6 29.6 25.6 31.0 21.9
K.W. 5.30 5.29 5.30 5.33 5.35 5.37 5.36 5.36 5.39 5.41 5.44 5.42 5.42 5.45 5.47
COOLING PERFORMANCE DATA - 5 TON
PACKAGED UNIT MODEL NO. PCG4B60
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1600 1800 2000
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 68.0 69.1 68.1 73.0 79.5 70.4 70.4 69.3 74.8 80.8 72.7 71.7 70.5 76.6 82.2
S.C. 63.3 54.8 46.2 43.7 36.0 66.7 57.0 48.8 46.3 37.1 70.1 59.2 51.4 48.8 38.2
K.W. 2.93 2.97 2.97 3.00 3.03 3.15 3.17 3.18 3.21 3.24 3.36 3.38 3.38 3.42 3.45
65 / 55
T.C. 64.1 65.4 64.3 69.7 75.7 66.2 66.4 65.1 71.0 76.5 68.4 67.5 65.9 72.3 77.4
S.C. 60.3 53.4 44.6 43.2 34.9 62.8 55.9 46.7 45.4 35.7 65.3 58.3 48.9 47.6 36.5
K.W. 3.25 3.27 3.28 3.31 3.35 3.46 3.48 3.49 3.52 3.56 3.68 3.69 3.69 3.73 3.77
75 / 63
T.C. 60.2 61.8 60.5 66.4 72.0 62.1 62.5 60.9 67.1 72.2 64.0 63.2 61.4 67.9 72.5
S.C. 57.4 52.0 43.1 42.7 33.7 59.0 54.7 44.7 44.5 34.3 60.6 57.5 46.3 46.3 34.9
K.W. 3.56 3.58 3.59 3.63 3.67 3.78 3.79 3.80 3.84 3.88 3.99 4.00 4.01 4.04 4.08
85 / 69
T.C. 57.4 57.1 56.2 61.8 67.1 58.7 57.8 56.6 62.3 67.4 60.0 58.4 57.0 62.9 67.7
S.C. 55.0 49.4 41.1 40.5 31.6 56.2 52.2 43.1 42.5 32.8 57.5 55.0 45.1 44.5 33.9
K.W. 3.98 4.00 4.01 4.04 4.07 4.19 4.21 4.21 4.24 4.28 4.41 4.42 4.42 4.45 4.48
95 / 75
T.C. 54.5 52.4 52.0 57.1 62.3 55.3 53.0 52.3 57.5 62.6 56.1 53.7 52.5 57.9 62.9
S.C. 52.6 46.9 39.2 38.2 29.4 53.5 49.7 41.5 40.4 31.2 54.4 52.5 43.8 42.6 33.0
K.W. 4.40 4.42 4.42 4.44 4.48 4.61 4.62 4.62 4.65 4.68 4.82 4.83 4.83 4.86 4.88
105 / 83
T.C. 52.1 47.2 45.9 51.1 55.2 52.5 47.6 45.6 51.0 55.2 52.8 47.9 45.2 50.9 55.1
S.C. 49.5 42.1 36.3 36.0 26.7 50.0 44.0 37.3 37.8 28.1 50.4 45.8 38.3 39.7 29.5
K.W. 5.03 4.99 4.99 5.01 5.05 5.22 5.19 5.19 5.22 5.25 5.40 5.40 5.40 5.42 5.45
115 / 89
T.C. 49.8 42.2 40.0 45.3 48.3 49.8 42.3 39.0 44.7 47.9 49.7 42.3 38.1 44.0 47.5
S.C. 46.6 37.5 33.4 33.8 24.0 46.6 38.4 33.3 35.3 25.0 46.6 39.4 33.1 36.9 26.0
K.W. 5.65 5.54 5.54 5.57 5.60 5.80 5.75 5.74 5.77 5.80 5.96 5.95 5.95 5.97 6.00
125 / 95
T.C. 47.5 37.1 34.1 39.5 41.4 47.1 36.9 32.5 38.3 40.7 46.6 36.8 31.0 37.2 39.9
S.C. 43.6 32.8 30.6 31.6 21.3 43.1 32.9 29.2 32.8 21.9 42.7 32.9 27.8 34.1 22.6
K.W. 6.27 6.09 6.09 6.12 6.15 6.39 6.30 6.30 6.32 6.35 6.52 6.51 6.50 6.52 6.55
