Coleman PCG4B60 - Cooling Performance Data - 3 Ton; Cooling Performance Data - 3.5 Ton

5564041-CTG-A-1018
Johnson Controls Unitary Products 7
COOLING PERFORMANCE DATA - 3 TON
PACKAGED UNIT MODEL NO. PCG4A36
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1000 1200 1400
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 36.0 38.3 40.3 44.9 48.1 38.9 40.4 42.1 46.8 49.8 41.8 42.5 43.9 48.8 51.5
S.C. 34.5 30.6 27.6 27.9 22.6 37.1 33.8 29.9 30.2 23.9 39.6 37.1 32.2 32.5 25.1
K.W. 1.82 1.83 1.83 1.83 1.85 1.89 1.90 1.90 1.91 1.92 1.97 1.97 1.98 1.99 1.99
65 / 55
T.C. 34.6 36.4 37.4 42.6 46.1 37.3 38.3 39.4 44.2 47.9 40.0 40.2 41.3 45.9 49.8
S.C. 33.2 29.8 26.0 26.8 21.6 35.6 32.9 28.5 28.9 23.4 37.9 36.1 31.0 31.1 25.1
K.W. 2.01 2.02 2.02 2.03 2.04 2.09 2.09 2.09 2.10 2.11 2.16 2.16 2.17 2.18 2.19
75 / 63
T.C. 33.2 34.6 34.5 40.3 44.0 35.7 36.3 36.6 41.7 46.1 38.1 37.9 38.7 43.1 48.2
S.C. 32.0 28.9 24.5 25.7 20.7 34.1 32.0 27.2 27.7 22.9 36.1 35.2 29.9 29.7 25.0
K.W. 2.20 2.20 2.21 2.22 2.23 2.28 2.28 2.28 2.30 2.30 2.36 2.36 2.36 2.37 2.38
85 / 69
T.C. 31.7 32.6 32.2 37.8 41.2 34.0 34.0 33.8 38.9 42.8 36.3 35.4 35.4 40.1 44.5
S.C. 30.4 26.9 23.3 24.6 19.3 32.4 30.3 25.8 26.5 21.1 34.5 33.7 28.2 28.4 22.8
K.W. 2.46 2.44 2.47 2.48 2.49 2.53 2.53 2.54 2.55 2.56 2.61 2.61 2.61 2.63 2.63
95 / 75
T.C. 30.1 30.6 29.8 35.3 38.4 32.3 31.7 31.0 36.2 39.6 34.5 32.8 32.1 37.1 40.8
S.C. 28.8 25.0 22.2 23.4 17.9 30.8 28.6 24.3 25.3 19.3 32.8 32.2 26.5 27.2 20.7
K.W. 2.72 2.67 2.73 2.74 2.74 2.79 2.77 2.80 2.81 2.82 2.87 2.87 2.87 2.88 2.89
105 / 83
T.C. 29.0 28.3 27.8 32.8 36.1 31.1 29.6 28.9 33.8 37.1 33.3 30.8 29.9 34.7 38.1
S.C. 27.5 23.9 20.9 21.8 16.9 29.4 27.1 22.9 23.8 18.2 31.3 30.4 25.0 25.8 19.6
K.W. 2.91 2.92 2.95 2.96 2.97 2.95 3.01 3.02 3.04 3.05 2.98 3.10 3.10 3.11 3.12
115 / 89
T.C. 27.9 26.0 25.9 30.4 33.9 30.0 27.4 26.8 31.4 34.7 32.1 28.9 27.8 32.3 35.5
S.C. 26.3 22.9 19.6 20.3 15.9 28.1 25.8 21.6 22.3 17.2 29.9 28.6 23.5 24.4 18.5
K.W. 3.11 3.16 3.17 3.19 3.20 3.10 3.24 3.24 3.26 3.27 3.10 3.32 3.32 3.33 3.35
125 / 95
T.C. 26.8 23.8 24.0 28.0 31.7 28.9 25.3 24.8 29.0 32.3 31.0 26.9 25.6 30.0 33.0
S.C. 25.1 21.9 18.3 18.7 14.9 26.8 24.4 20.2 20.9 16.2 28.5 26.9 22.1 23.1 17.4
K.W. 3.30 3.39 3.39 3.41 3.42 3.25 3.47 3.46 3.48 3.49 3.21 3.55 3.54 3.55 3.57
COOLING PERFORMANCE DATA - 3.5 TON
PACKAGED UNIT MODEL NO. PCG4A42
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1200 1400 1600
IDDB 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
IDWB 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
55 / 45
T.C. 43.7 46.9 46.8 51.8 57.3 46.5 48.6 48.5 53.7 59.6 49.4 50.2 50.2 55.5 61.9
S.C. 43.1 39.2 33.9 34.4 28.7 45.5 42.1 36.2 37.0 30.7 47.8 45.0 38.5 39.6 32.6
K.W. 2.35 2.36 2.36 2.38 2.38 2.42 2.44 2.43 2.45 2.47 2.50 2.52 2.51 2.53 2.56
65 / 55
T.C. 42.2 44.1 44.1 48.9 54.1 44.4 45.6 45.6 50.5 56.1 46.6 47.0 47.0 52.1 58.0
S.C. 41.9 37.7 32.5 32.8 27.5 43.7 40.5 34.4 35.3 29.2 45.5 43.2 36.4 37.7 30.8
K.W. 2.36 2.61 2.59 2.62 2.61 2.55 2.68 2.66 2.70 2.71 2.73 2.76 2.74 2.77 2.80
75 / 63
T.C. 40.6 41.3 41.4 46.0 51.0 42.2 42.6 42.6 47.4 52.5 43.8 43.9 43.7 48.7 54.1
S.C. 40.6 36.3 31.0 31.3 26.2 41.9 38.8 32.7 33.6 27.6 43.3 41.4 34.3 35.9 29.0
K.W. 2.38 2.86 2.82 2.87 2.84 2.67 2.93 2.89 2.94 2.94 2.97 3.00 2.97 3.01 3.04
85 / 69
T.C. 38.0 38.2 38.4 42.7 47.6 39.3 40.0 39.3 43.8 48.8 40.7 41.8 40.1 44.9 50.0
S.C. 38.0 34.5 29.3 28.5 24.5 39.2 36.1 31.0 31.2 25.9 40.4 37.7 32.8 33.9 27.3
K.W. 2.69 3.17 3.13 3.18 3.15 2.98 3.24 3.20 3.24 3.26 3.28 3.30 3.28 3.31 3.36
95 / 75
T.C. 35.4 35.1 35.4 39.3 44.1 36.5 37.4 35.9 40.2 45.1 37.6 39.7 36.5 41.1 46.0
S.C. 35.4 32.7 27.6 25.8 22.8 36.5 33.3 29.4 28.9 24.1 37.6 33.9 31.3 32.0 25.5
K.W. 3.00 3.48 3.44 3.48 3.47 3.29 3.54 3.51 3.54 3.57 3.59 3.60 3.59 3.60 3.67
105 / 83
T.C. 31.7 31.2 31.2 34.9 39.4 32.5 33.0 31.5 35.5 40.0 33.3 34.8 31.8 36.1 40.6
S.C. 31.7 29.6 25.4 24.5 20.9 32.5 30.3 26.9 27.0 22.1 33.3 31.0 28.4 29.5 23.3
K.W. 3.44 3.90 3.86 3.90 3.90 3.72 3.97 3.94 3.97 3.99 4.01 4.03 4.01 4.03 4.09
115 / 89
T.C. 28.2 27.4 27.1 30.7 34.7 28.7 28.8 27.2 30.9 35.0 29.2 30.1 27.3 31.1 35.3
S.C. 28.2 26.7 23.3 23.1 19.0 28.7 27.4 24.4 25.2 20.1 29.2 28.2 25.6 27.2 21.2
K.W. 3.86 4.31 4.28 4.30 4.31 4.14 4.38 4.35 4.37 4.41 4.43 4.45 4.42 4.45 4.50
125 / 95
T.C. 24.7 23.7 23.0 26.5 30.1 24.9 24.5 22.9 26.4 30.1 25.1 25.4 22.8 26.2 30.1
S.C. 24.7 23.7 21.2 21.8 17.2 24.9 24.5 22.0 23.3 18.1 25.1 25.4 22.8 24.8 19.1
K.W. 4.29 4.71 4.69 4.70 4.73 4.57 4.79 4.76 4.78 4.82 4.84 4.86 4.83 4.87 4.91
