Coleman PCG4B60 - Unit Typical Duct Applications; Unit Typical Slab on Ground Installation

5564041-CTG-A-1018
16 Johnson Controls Unitary Products
UNIT TYPICAL DUCT APPLICATIONS
ROOF CURB
INSTALLATION
REAR DUCT
ROOF CURB
INSTALLATION
BOTTOM DUCT
SLAB ON
GROUND
INSTALLATION
A03
2
UNIT TYPICAL SLAB ON GROUND INSTALLATION
A0325-001
SUPPLY
AIR DUCT
TO POWER SUPPLY
RETURN
AIR DUCT
FIELD-SUPPLIED
DISCONNECT
SWITCH
CONTROL WIRING TO
INDOOR THERMOSTAT
TO GAS
SUPPLY LINE
MANUAL GAS
SHUTOFF VAVLE
CONDENSATE
DRAIN
