5564041-CTG-A-1018
14 Johnson Controls Unitary Products
1. Airflow tested with dry coil conditions, without air filters, at 230 volts
2. Applications above 0.8" w.c. external static pressure are not recommended.
3. Brushless DC high efficiency standard ECM blower motor used for all indoor blower assemblies.
4. Minimal variations in airflow performance data results from operating at 208 volts. Data above may be used in those cases.
5. Heating applications tested at 0.50" w.c. esp, and cooling applications tested at 0.30" w.c.esp per standards.
48125
Low (1) 1598 1548 1502 1454 1410 1362 1307 1251 1139
Low/Medium (2) 1766 1703 1656 1611 1566 1518 1469 1419 1319
Medium (3) 1912 1875 1805 1787 1750 1713 1672 1636 1564
Medium/High (4) 2105 2014 2006 1931 1898 1845 1793 1739 1631
High (5) 2131 2058 1998 1949 1892 1840 1788 1728 1608
60065
Low (1) 1026 999 989 950 907 907 886 862 816
Low/Medium (2) 1263 1230 1192 1165 1167 1101 1099 1071 1015
Medium (3) 1987 1933 1861 1817 1820 1715 1725 1651 1504
Medium/High (4) 2114 2050 2047 1974 1899 1889 1920 1866 1758
High (5) 2369 2308 2249 2183 2126 2088 2034 1990 1902
60100
Low (1) 1655 1612 1596 1531 1461 1462 1429 1391 1316
Low/Medium (2) 1766 1720 1667 1629 1632 1539 1537 1498 1421
Medium (3) 1987 1933 1861 1817 1820 1715 1725 1651 1504
Medium/High (4) 2114 2050 2047 1974 1899 1889 1920 1866 1758
High (5) 2369 2308 2249 2183 2126 2088 2034 1990 1902
60125
Low (1) 1973 1924 1905 1826 1743 1744 1703 1660 1574
Low/Medium (2) 2024 1983 1937 1889 1886 1843 1799 1759 1679
Medium (3) 2123 2075 2019 1970 1978 1862 1849 1804 1714
Medium/High (4) 2191 2154 2117 2075 2002 1995 2028 1974 1866
High (5) 2369 2308 2249 2183 2126 2088 2034 1990 1902
AIRFLOW PERFORMANCE - BOTTOM DUCT APPLICATION (Continued)
Model Motor Speed
External Static Pressure (Inches WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 1.0
SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM SCFM
