20
WORK
1. PREPARING TO WORK
1. Connect the connector (1) to the batteries (versions without built-in BC), this is already connected for
the versions with the BC already built in, while for the electric versions, connect the power cable to the
mains.
ATTENTION: before using the machine, the operators must be suitable trained.
We therefore suggest you read this instruction booklet carefully and read it again
whenever difficulties arise while using the machine
1
2. Turn the key (2) of the main switch to position “1” (clockwise). The monitor (3) on the instrument panel
will immediately come on.
ATTENTION: if the machine is used in places where there is a risk of falling
objects, the operator must be provided with all the appropriate protection devices
as laid out in the legal requirements
3. With switch-on, three consecutive screens are visualised on the monitor. The first screen shows (on
the top line) what type of hour-counter has been set; in this case it's a total hour-counter (to visualise a
different type - for instance partial - contact the qualified, COMAC-trained personnel). The bottom line
shows the “serv. nev.” setting (in this case there is no setting).
4. The second screen displays what battery technology has been set for machine operation or the mains
power supply (mains) for the electric versions. In this example, it's lead batteries (to set another type of
battery - for instance gel - contact the qualified, COMAC-trained personnel).
5. The third and last screen (known as “work”) visualises the battery charge status and the total
functioning time. When the batteries supplied are fully charged, the upper line contains 8 light indicators
that represent a battery. As the batteries gradually run down, the indicators go out and, with the batteries
completely run down, only the battery outline flashes. The bottom line indicates the hours and minutes of
functioning. The flashing “:” symbol indicates that the hour-counter is counting the machine functioning
time.
2
1
3
