SYMBOLS USED ON THE MACHINE
Water regulation symbol (l/h), DS system. Used on the instrument panel to indicate the adjustment of the amount
of water distributed to the brushes (for DS system)
Detergent regulation symbol (%), DS system. Used on the instrument panel to indicate the adjustment of the
detergent percentage dissolved in the water (for DS system)
Main switch symbol (key switch)
Water regulation symbol
Printed on the solution tank to indicate the position of the tap
Indicates the maximum gradient
Indication showing the battery charge level on the upper line and hour-counter on the lower line
Indication showing the type of hour-counter (total) on the upper line and the type of service (none) on the lower
line
Indication of the type of battery technology in use (lead-gel) or the mains power supply
Battery symbol
Indicates the maximum temperature of the detergent solution
Located near the solution tank inlet
