21
WORK
6. Release the lever (4) and lower the base.
7. Lower the squeegee, turning the lever (5) anticlockwise. The suction motor will start when fully
lowered. To switch off the suction motor, turn the key to position “0” once the work is finished.
8. Check the brake (6) is off.
9. By pressing the "dead man's" levers (7), the brush is activated and the machine begins to move.
During the first metres, check there is sufficient solution and that the squeegee dries perfectly.
10. The machine will now begin to work efficiently until the cleaning solution finishes or the battery is flat
(for battery versions).
2. OVERFLOW DEVICE
The machine is fitted with a float which intervenes when the recovery tank is full, causing the suction tube
to close. In this case the recovery tank must be emptied by removing the cap of the rear discharge pipe
WARNING: you are advised to always wear protective gloves in order to avoid
the risk of serious injury to your hands
7
4
5
6
