Installation
NOTE:
InteliGen NT or InteliSys NT controller (any of their hardware modification) equipped with the "IGS-NT-LSM-
PMS" dongle and programmed with IG-NT-BC or IS-NT-BC firmware must be used at the place of the Bank
controller.
NOTE:
It is not possible to monitor the whole multisite using one InteliMonitor. Each CAN bus must be monitored
separately.
CAN bus wiring
CAUTION!
Each controller in one segment of the CAN bus must contain unique controller address!
Inter gen-set controller CAN (CAN-B)
The Bank controller is connected with the gen-sets inside the bank via the CAN1 interface. That means
although the gen-set controllers are connected to the intrabank bus via their CAN2 interface the bank
controller uses CAN1 instead. The bank controller has fixed address 32, so gen-set controllers can use
address 1-31. See the Figure: CAN bus wiring.
NOTE:
The gen-set controller is never connected directly to the CAN-A but it has to be always subordinated to
some BankController.
NOTE:
The request of the Bank Controller to run it´s subordinated gen-sets is distributed internally via CAN-B as
internal command Syst start/stop. It is not needed to be configured in the subordinated gen-set.
Interbank CAN (CAN-A)
Bank controllers are connected together via their CAN2 bus. The interbank bus can also contain InteliMains-
NT controllers. Address of the bank controller is adjusted by the setpoint Comm Settings: Controller Address.
NOTE:
It is not possible to use any peripherial module at CAN1 interface of the bank controller.
NOTE:
It is not possible to use InteliMains-NT controllers within the bank. The bank must contain only InteliGen NT
or InteliSys NT controllers with standard firmware and special “MINT-BC” archive.
NOTE:
The general rules for CAN bus wiring remain valid, i.e. the total length of the CAN bus must not exceed
200m (250kbps) or 800m (50kbps).
