Inputs and Outputs
Virtual and physical modules
Number of I/O can be extended and project wiring can be reduced using the following extension and virtual
modules.
Module
name
BIN
BOUT
AIN
AOUT
IMPULSE
Note
IGS-NT
controller
x
x
x
x
Number of I/O depends on type.
IGS-PTM
8
8
4
1
-
Standard I/O extension module.
IS-AIN8
-
-
8
-
-
Standard I/O extension module.
IS-AIN8TC
-
-
8
-
-
8 thermocouple inputs
IS-BIN16/8
16
8
-
-
-
Standard I/O extension module.
InteliAIN8
-
-
8
-
2
InteliAIN8TC
-
-
8
-
-
InteliIO8/8
8
8
-
2
-
InteliIO16/0
16
0
-
2
-
I-CB
x
x
x
x
-
Configurable communication bridge.
IGL-RA15
-
15
-
-
-
15 Green, Red, Yellow LED panel.
I-AOUT8
-
-
-
8
-
8 Analog outputs
VPIO
8
8
-
-
-
Virtual periphery I/O module.
SHBIN
8
-
-
-
-
SHared (virtual) Binary INput module
SHBOUT
-
8
-
-
-
SHared (virtual) Binary OUTput module
SHAIN
-
-
8
-
-
Shared (virtual) Analog INput module
SHAOUT
-
-
-
8
-
Shared (virtual) Analog OUTput module
PLC
x
x
x
x
-
Programmable (internal) logic module.
HINT
For more details about Virtual peripherals (Shared and Internal virtual I/O periphery and PLC) see IGS-NT-
Application guide-2.4.pdf.
CAUTION!
Usage of any 3rd-party peripheral modules in cooperation with ComAp controller is not recommended.
ComAp can’t guarantee the proper function of controller with none-ComAp peripheral modules.
