situation, e.g. mains failure and/or mains return:
1. Select a binary signal in the controller, which indicates, that the particular
situation occured, about which you want to be informed remotely. There
are many predefined binary informations provided directly by the
controller or use PLC functions to create the desired binary signal.
2. Configure an universal protection block to the binary signal mentioned
above and select protection type AL indication.
3. Configure the binary signal mentioned above onto the logical binary input
IssueActCallC5.
Binary input: AccessLock D#2
This input forces the external local terminal or IntelliVision (display) #2 into
monitoring mode.
NOTE:
Local display means that it is connected to dedicated RS485. There is possibility
to connect up to 2 external displays in IG-NT-BB or 1 in IG-NT. It is possible to
connect up to 3 external displays in IS-NT-BB and in IS-NT.
• Setpoints changes are disabled.
• Using control buttons on the panel is disabled even if the controller is in
MAN mode.
• Change of controller mode is disabled.
Binary input: AccessLock D#3
NOTE:
For IS-NT and IS-NT-BB only.
This input forces the external local terminal or IntelliVision (display) #3 into
monitoring mode.
NOTE:
Local display means that it is connected to dedicated RS485. There is possibility
to connect up to 2 external displays in IG-NT-BB or 1 in IG-NT. It is possible to
connect up to 3 external displays in IS-NT-BB and in IS-NT.
• Setpoints changes are disabled.
• Using control buttons on the panel is disabled even if the controller is in
MAN mode.
• Change of controller mode is disabled.
Binary input: NeutralCB fdb
