IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
source. The shared peripherial modules can be used to distribute the value over
the controllers via the CAN2 bus. See the note in the description of the setpoint
SysBaseLdMode.
Analog input: Cold temp 1
If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #1.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Analog input: Cold temp 2
If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #2.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Analog input: Cold temp 3
If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #3.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
