ComAp IG-NTC GC - Page 74

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
74
Setpoint: Vb VT ratio
Group
Basic Settings
Range [units]
0.1 .. 500.0 [V/V]
Related FW
3.0
Description
The setpoint is used to adjust the bus voltage transformers ratio.
NOTE:
See all notes mentioned above.
Setpoint: Vm InpRangeSel
Group
Basic settings
Range [units]
277V, 120V [-]
Related FW
3.0
Description
This setpoint selects the range of the mains voltage terminals. The 120V range is
available only in IG-NTC and IS-NT. The IG-NT has the range adjusted fixedly to
277V regardless of this setpoint.
NOTE:
The 277V range is suitable for both European (230V) and American (277V)
measurement. The range 120V is intended for high-voltage applications where
voltage transformers with 100V secondary range are used or for alternative
American (120V) measurement.
Setpoint: Vb InpRangeSel
Group
Basic settings
Range [units]
277V, 120V [-]
Related FW
3.0
Description
This setpoint selects the range of the bus voltage terminals. The 120V range is
available only in IG-NTC and IS-NT. The IG-NT has the range adjusted fixedly to
277V regardless of this setpoint.
NOTE:
See all notes mentioned above.
Setpoint: BankNomV
Group
Basic Settings
Range [units]
10 .. 34641 [V]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used to adjust the nominal (rated) generator voltage (phase to
neutral). If you do not know the phase-neutral nominal voltage, you can adjust the
phase-phase nominal voltage GenNomVph-ph. The controller will then recalculate
