Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
15
Protections and Alarm management
Protection groups
There are two groups of protections in the controller: fix and customer configurable.
Setpoint group
Analog protections Configurable Analog protect
Generator protections Configurable Gener protect
Mains protections –
should not be used in
MINT application
Configurable Mains protect
Fix protections Fix Engine params,
Gener protect,
Analog protect
Protection types
Because of limited (adjustable) GeCon influence to the Engine and GCB (depends on configuration and
wiring) the GeCon protection system is more focused to fail indication. All Protection types are available
because of IGS-NT system compatibility even if some Protection types has the same result in GeCon (e.g.
BOC, Stp, Sd).
Level Protection
types
Abbre
viation
Gen-set action Record
1
History record
Hst none History only
1
Alarm only
Al none Alarmlist only
1
Warning
Wrn none Alarmlist and History
2
Off load
OfL AUT modes:
Controller opens GCB without soft
unloading, gen-set runs 1 minute at
Nominal RPM. Gen-set state changes to
Running 1 minute after Off load activation.
Controller starts automatically GCB
synchronizing (or closes GCB) when Off
load is deactivated (no fault reset
necessary).
MAN mode:
Controller opens GCB without soft
unloading and the gen-set runs without
load until operator intervention.
All generator protections are active during
Off load duty.
Alarmlist and History
2
Breaker Open
& Cool-down
BOC Controller opens GCB without soft
unloading, gen-set state changes to
Running.
Alarmlist and History
2
Slow stop
Stp Soft unloading then the GCB opens, BO:
Stop pulse; the gen-set state changes to
Stopping.
Alarmlist and History
2
Shutdown
Sd Controller opens GCB without soft
unloading.
Alarmlist and History
X
Sensor fail
Fls Can be indicated when Analog input value
is ±6% out of sensor characteristic range.
Fls can optionally activate corresponding
(e.g. Sd) Analog input protection as well.
Alarmlist and History
