Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
62
ExtValue1 rate [ X/s ] (FV)
ExtValue2 rate [ X/s ] (FV)
ExtValue3 rate [ X/s ] (FV)
ExtValue4 rate [ X/s ] (FV)
ExtValueX rate of change per second. If the binary input ExtValueX down or ExtValueX up is active, the
value is changed according to this rate.
Step: 1 X/s
Range: 1 – 10000 X/s
Hint:
If binary input ExtValueXreset is active, the corresponding ExtValueX is held at its default value, regardless
of the activity of inputs Up and Down and regardless of incoming external set commands.
Using this function in combination with Force value you can externally control selected setpoints’ values and
achieve some special behaviour of the controller.
ExtValue1deflt [ X ] (FV)
ExtValue2deflt [ X ] (FV)
ExtValue3deflt [ X ] (FV)
ExtValue4deflt [ X ] (FV)
ExtValueX default (starting) value. If ExtValueX is changed from this default value using Modbus command,
the new value is kept in ExtValueX until another command arrives or until the controller has been switched
off. If the binary input ExtValueXreset is active, the ExtValueX is held at this value regardless of other
conditions.
Step: 1 X
Range: -32000 – 32000 X
Load shedding
Ld shed level [ % ] (FV)
When gen-set load exceeds this level for more than Ld shed delay time, controller proceeds to the next Load
shedding stage - the next binary output Load shed x is closed.
Step: 1 % of Nomin power
Range: Ld recon level - 200 % of Nomin power
Force value: Yes
Ld shed delay [ s ] (FV)
Time delay for LD shed level limit.
Step: 0,1 s
Range: 0,0 – 600,0 s
Force value: Yes
Ld recon level [ % ] (FV)
When gen-set load drops under this level for more than Ld recon delay time, controller proceeds to the lower
Load shedding stage. The binary output for higher stage is opened (Load shed x). Automatic load
reconnection works only when AutoLd recon = ENABLED.
Step: 1 % of Nomin power
Range: 0 - Ld shed level
Force value: Yes
