ComAp IG-NTC User Manual

Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
32
Sd L1 over
Sd L2 over
Sd L3 over
Shut-down
Gener protect: Gen >V SD
Gener protect: Gen V del
Gen V L1-N
Gen V L2-N
Gen V L3-N
BreakerOpen & Cool-down
Shut-down
Gener protect: Gen <V BOC
Gener protect: Gen >V BOC
Gener protect: Gen >V SD
Gener protect: Gen V del
Basic settings: VoltProtSelect = PHASE-PHASE
Binary output name Protection type Based on setpoint
BOC L12 under
BOC L23 under
BOC L31 under
BreakerOpen & Cool-down
Gener protect: Gen <V BOC
Gener protect: Gen V del
BOC L12 over
BOC L23 over
BOC L31 over
BreakerOpen & Cool-down
Gener protect: Gen >V BOC
Gener protect: Gen V del
Sd L12 over
Sd L23 over
Sd L31 over
Shut-down
Gener protect: Gen >V SD
Gener protect: Gen V del
Gen V L1-L2
Gen V L2-L3
Gen V L3-L1
BreakerOpen & Cool-down
Shut-down
Gener protect: Gen <V BOC
Gener protect: Gen >V BOC
Gener protect: Gen >V SD
Gener protect: Gen V del
BOC fgen under
Generator protect: Gen <f and Gen f del.
BOC fgen over
Generator protect: Gen >f and Gen f del.
Gen freq
BreakerOpen & Cool-down
Generator protect: Gen >f, Gen <f and Gen f del.
Hint:
L1-N, L2-N, L3-N alarm indications are active when Basic settings: VoltProtSelect = PHASE-NEUTRAL.
L1-L2, L2-L3, L3-L1 alarm indications are active when Basic settings: VoltProtSelect = PHASE-PHASE.
OfL StartBlck
Output indicates wrong setpoints setting that disables the engine start or taking the load.
Binary output name Protection type Based on setpoint
BOC IDMT
BreakerOpen & Cool-down Generator protect: 2Inom del.
BOC ShortCurr
BreakerOpen & Cool-down Generator protect: Ishort and Ishort del.
BOC Overload
BreakerOpen & Cool-down Generator protect: OverldStrtEval
Generator protect: 2POverldStEvDel
BOC NCB fail
BreakerOpen & Cool-down
Binary outputs – Power management
SystReady
The output is closed when the system is able to reach (not reached !) requested power reserve.
Syst res OK
The output closes when selected system load reserve is achieved within the gen-set group.
P
BNom
> P
Akt
+ Reserve
P
BNom
Sum of the nominal power of all gen-sets in the gen-set logical group
P
Akt
System load
Reserve selected setpoint
Pwr management: #LoadResStrt X
In relative mode, actual relative load reserve of the gen-sets is calculated and compared with required
relative load reserve (
Pwr management: #%LdResStrt X).
