Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
31
Dongle incomp
Incompatible dongle indication.
Emergency stop
Activity of Emergency stop (from Binary input Emergency stop) indication.
Hint:
Any Binary output alarm indication that follows the corresponding internal state is activated with alarm and
stays active until alarm reason disappears and the Fault reset (panel button or remote) is activated.
Stp GCB fail
Output closes when GCB fail is detected.
BOC NCB fail
Output closes when NCB (Neutral circuit breaker) fail is detected.
Stp Sync fail
The output is closed when the alarm Sync timeout is active.
WrnSpdRegLim
Output indicates the controller Speed governor output is on limit.
WrnVoltRegLim
Output indicates the controller AVRi output is on limit.
Hint:
When Speed governor output stays near to the limit value (SpeedGovLowLim+0,2 V or SpeedGovHiLim-0,2
V) for more than 2 sec, the “Wrn SpdRegLim” message is displayed in the Alarm list and recorded to History.
When AVRi output stays on <2% or >98% for more than 2 sec, the “Wrn VoltRegLim” is displayed in the
Alarm list and recorded to History.
UnivState 1 … Univ state 15
Universal state 1 to Universal state 15 activity indication. Universal state can be used for additional
protection configured to any internal value.
RPM
Indication of RPM state.
CAN2 bus empty
The output closes if the controller doesn’t “see” any other controllers on the CAN2 bus. The output activation
can be blocked by setpoint
Basic settings:DetectOtherCAN (So it should be DISABLED for single
applications.)
WrnService time
The output closes when at least one of gen-set Service count down timers Service time X has reached zero.
To reset the output (and the related Wrn alarm), it is necessary to set again a non-zero value to the
corresponding setpoint.
Generator Voltage and Frequency alarms indication
Basic settings: VoltProtSelect = PHASE-NEUTRAL
Binary output name Protection type Based on setpoint
BOC L1 under
BOC L2 under
BOC L3 under
BreakerOpen & Cool-down
Gener protect: Gen <V BOC, Gen V del
BOC L1 over
BOC L2 over
BOC L3 over
BreakerOpen & Cool-down
Gener protect: Gen >V BOC, Gen V del
