Inteli NT GeCon MINT, SW Version 1.4, ©ComAp – June 2007
IGS-NT-GeCon-MINT-1.4.PDF
30
Horn flashing
If any alarm comes up, the output starts periodic closing/opening with period 1s/1s. It opens and stays open
if FAULT RESET or HORN RESET is pressed or if
Engine protect: Horn timeout has elapsed.
Vgen <>
The output closes if the generator over/under voltage alarm activates.
Vbus <>
The output closes if the bus over/under voltage is detected.
Overcurrent
The output closes if the generator IDMT Overcurrent or Current Unbalance or Shortcurrent alarm activates.
The output opens, if none of these alarms is active and FAULT RESET has been pressed.
ECU comm error
Output closes if there is an error in the communication with ECU. It doesn’t matter how the ECU is
connected – J1939 link or RS232 line.
PeriphCommErr
Output closes if there is an error in the communication with any peripheral unit (e.g. IS-AIN8, IGS-PTM, ...).
Bus meas error
The output closes when bus measurement protection is activated according to description of Gener
protect:BusMeasError setpoint.
Binary outputs – Configurable prog. States
SHBinCfGErr
Shared Binary module configuration error – i.e. more than one source was configured (is on the CAN2 bus).
SHAinCfgErr
Shared Analog module configuration error – i.e. more than one source was configured (is on the CAN2 bus).
PLC State 1 .. 4
PLC state indication.
ECUDiagBlocked
Output is active when Basic setting: ECU diag = DISABLED.
WrongConfig
Wrong configuratio indication.
Reverse power
Output is active when reverse power protection is active. Based on Gener protect: Reverse power and
RevPower del.
Batt volt
Indication of battery voltage protection based on Analog protection: Batt >V, Batt <V, Batt V del.
EarthFaultCurr
Indication of Earth fault current protection based on Gener protect: EarthFaultCurr and EthFltCurr del.
