Hint:
Available from the MEASUREMENT screens only.
How to view Connection screen on IG-Display?
Press ↑ button when in Info screen to see information about IG-Display hardware
version and properties and actual state of communication with the master controller.
How to change the display backlight intensity?
Hold down the ENTER and then press ESC. On the display you can see Controller
INFO screen for 10 seconds.
Press and hold ENTER when in INFO screen and use ↑ or ↓ to adjust the best
display backlight.
Backlight intensity is set for one of the two modes, depending on the activity of
configurable binary input Alt brightness (IG-NT/EE and modifications). For IG-Display
and IS-Display modules, this binary input is located in the Power connector and it’s
function is fixed (not configurable).
IS-Display with address 1 reads analog input LCD brightness on IS-NT-BB and
changes accordingly display backlight intensity in the range 0-100%.
Hint:
Backlight intensity change available from the MEASUREMENT screens only.
How to find active alarms?
Select Alarmlist menu item and press ENTER or press ← in MEASUREMENT IO or
MEASUREMENT CU menu.
Inverted alarms are still active. Non-inverted alarms are not active, but not yet
confirmed.
Press FAULT RESET to accept all alarms (an asterix mark disappears when an
alarm is accepted by FAULT RESET). Non-active alarms immediately disappear
from the list.
Active alarm list appears on the screen automatically when a new alarm comes up
and Main MEASUREMENT screen was selected.
Hint:
Alarm list does not activate automatically if the display is switched to any other
screen than the first one of MEASUREMENT (typically the screen that shows menu
selector on the upper). The automatic jump to the alarm list screen will not occur if
you are listing through the measured values, set points or history!
InteliVision 5, InteliVision 8 – Operator guide, ©ComAp – January 2014
IGS-NT Operator Guide 01-2014.pdf
43
