InteliLite Global Guide
176
Setpoint group Basic settings Related FW 1.9.0
Range [units] 1 .. 5 000 [kW]
Default value 200 kW Alternative config Yes
Step 1 kW
Comm object 8276 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Nominal power of the gen-set. Generator Overload BOC (page 227) protection is based on this setpoint.
Note: This setpoint is used when setpoint Connection type (page 177) is adjusted to 3Ph3Wire or High
Leg D or 3Ph4Wire or when Autodetect detects connection type as 3Ph3Wire or High Leg D or
3Ph4Wire.
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Power 1 (page 333),
Nominal Power 2 (page 337) and Nominal Power 3 (page 341).
Nominal Power
6 back to List of setpoints
Subgroup: Current settings
Setpoint group Basic settings Related FW 1.9.0
Range [units] 1 .. 10 000 [A]
Default value 350 A Alternative config YES
Step 1 A
Comm object 8275 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 177).
Description
It is current limit for mains current protections and means maximal continuous mains current. Nominal
Current can be different from mains rated current value.
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Current 1 (page
331), Nominal Current 2 (page 335) and Nominal Current 3 (page 339).
Nominal Current
6 back to List of setpoints
