InteliLite
NT
– AMF20/25, SW version 2.2, ©ComAp – September 2014 140
IL-NT-AMF-2.2-Reference Guide.pdf
Power supply
Voltage supply 8-36V DC
Consumption 40-430mA depend on supply voltage and
temperature
Consumption depends on supply voltage 0,104A at 8VDC
0,080A at 12VDC
0,051A at 24VDC
0,044A at 30VDC
0,040A at 36VDC
Allowed supply voltage drop-out: 100ms from min. 10V, return to min. 8V
Battery voltage measurement tolerance 2 % at 24V
Hint:
For the supply voltage less than 7V the backlight of the display is switched off.
Short-term voltage drops (e.g. during the engine cranking) do not affect the operation at all.
Operating conditions
Operating temperature IL-NT -20..+70
o
C
Operating temperature IL-NT LT
#
-40..+70
o
C
Storage temperature -30..+80
o
C
Protection front panel IP65
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 61000-6-3:2006, EN 61000-6-3:2006
EN 61000-6-1:2005, EN 61000-6-2:1999
Vibration 2 – 25 Hz, ±1.6 mm
25 – 100 Hz, a = 4 g
Shocks a = 500 m/s
2
#
Low Temperature modification
LCD display limits controller operating temperature range to -20
o
C – + 70
o
C even if the other
electronic components work in wider temperature range.
Internal preheating foil is mounted in InteliLite
NT
LT to extend display operational temperature range.
Preheating starts at temperature below 5
o
C and preheating power depends on temperature and
power supply voltage.
Technical data
Order code:IL-NT-AMF25 LT
