ComAp intelilite nt amf25 User Manual

InteliLite
NT
– AMF20/25, SW version 2.2, ©ComAp – September 2014 145
IL-NT-AMF-2.2-Reference Guide.pdf
IGS-PTM
Voltage supply 8-36V DC
Consumption 0,1A depend on supply voltage
Mechanical dimensions: 40 x 95 x 45 mm, DIN rail (35 mm) mounted
Interface to controller CAN
Binary inputs and outputs see IG-IOM
Analog output see IG-IOM
Analog inputs
Not electrically separated
Number of inputs 4
Resolution 10 bits
Maximal resistance range 0 – 250 
Maximal voltage range 0 – 100 mV
Maximal current range 0 – 20 mA
Resistance measurement tolerance 1 %  2  out of measured value
Voltage measurement tolerance 1,5 %  1mV out of measured value
Current measurement tolerance 2,5 % 0,5mA out of measured value
IGL-RA15
Power supply
Voltage supply 8-36V DC
Consumption 0,35-0,1A (+1A max horn output)
Depend on supply voltage
Operating conditions
Operating temperature -20..+70
o
C
Storage temperature -40..+80
o
C
Protection front panel IP65
Dimensions and weight
Dimensions 180x120x55mm
Weight 950g
Horn output
Maximum current 1 A
Maximum switching voltage 36 VDC
IG-IB
Voltage supply 8-36V DC
Consumption 0,1A depend on supply voltage
Mechanical dimensions: 95 x 96 x 43 mm, DIN rail (35 mm) mounted
Interface to controller RS232
Interface to modem RS232
Interface to Ethernet RJ45 (10baseT)
Operating temperature -30..+70
o
C
Storage temperature -30..+70
o
C

ComAp intelilite nt amf25 Specifications

General

Communication Ports	RS232, RS485, USB
Power Supply	8-36 VDC
Number of Digital Inputs	8
Number of Digital Outputs	8
Number of Analog Inputs	3
Number of Analog Outputs	2
Display	LCD with backlight
Supported Protocols	Modbus
Operating Temperature	-20°C to +70°C
Humidity	95% non-condensing
Weight	0.4 kg
Protection	IP65 (front panel)
Controller Type	AMF Controller
Storage Temperature	-30 to +80 °C
