7.5 Fuses
The 14-way fuse box is mounted on the control
panel inside the operating enclosure. The fuses are
midi blade type fuse. They are arranged in the order
shown in the table to the right.
The rating of each fuse and the function relating to
each fuse is given in the table below.
14-Way Midi Blade Fuse Box Table
Fuse Amps Circuit
1 - Diesel 7.5
Mast Above Set Height Drive Cut-Out Override, Mast Height Override,
Dash Dis
p
la
y
Li
g
hts
,
Glow Plu
g
Li
g
ht
,
Glow Plu
g
Rela
y,
PLC Su
pp
l
y
1- Toyota LPG 7.5
Mast Height Override, Dash Display Lights, PLC Supply, LPG Relay,
En
g
ine Plu
g
s
1 – GM LPG 7.5 Mast Height Override, Dash Display Lights, PLC Supply
2 7.5
Joystick Supply, Neutral Relay, Reverse Bleeper, PLC X3, (Alternator
Plu
g
Pin 3
–
To
y
ota Onl
y)
3 - Diesel 7.5 Pull Hold Solenoid, Fuel Pump
3 – Toyota LPG 10 Engine Cut-Off, Distributor Plug J Pin 1
3 – GM LPG 7.5 Ignition Coil, Anti-Backfire
4 20 Steering Solenoid Supply, PLC Output Supply
5 7.5
Push Button Brake Switch, Inch Pedal Brake Switch, Brake Light, Brake
Solenoid Su
pp
l
y
6 7.5 Wiper Motor (If Fitted)
7 15 Front Work Lights, Dash Cluster Lights
8 15 Side Work Lights, Cabin Interior Light (If Fitted)
9 7.5 Cabin Heater (If Fitted), Cabin Cooling Fan (If Fitted), Radio (If Fitted)
10 7.5 Horn
11 7.5 Independent Fork Positioning Solenoids (If Fitted)
12 7.5 Proximity Switches Supply, Seat Switch, Seat Belt Switch (If Fitted)
13 7.5 Flashing Beacon
14 10 Optional Extras - 12v Power Socket, Air Seat, Extra Oil Cooler
Fuse 5 Fuse 10
Fuse 14
Fuse 4 Fuse 9
Fuse 13
Fuse 3 Fuse 8
Fuse 12
Fuse 2 Fuse 7
Fuse 11
Fuse 1 Fuse 6
