Some trucks may have additional relays that are not listed above. These
relays are for non-standard optional extras. Please Contact Combilift and
quote the truck serial number for information on the function related to
these rela
s.
The main fuse is mounted in the engine compartment under the bonnet and can be
accessed by opening the bonnet from the right hand side of the truck. The fuse is
located below the bonnet gas strut.
The valve chest solenoid lockout valve fuse is mounted in the engine compartment
under the bonnet and can be accessed by opening the bonnet from the right hand
side of the truck. The fuse is located below the bonnet gas strut.
Engine Compartment Fuse Table
Fuse Amps Function
Maxi Blade 80 Main Fuse
Midi Blade 10 Valve Chest Lockout Valves
7.6 Relays
The relays are mounted inside the control panel and can be accessed by removing
the cover plates.
The following table gives the function related to each of the relays fitted as standard.
Relay Function
1 Starter Solenoid
2 Glow Plug Timer (Diesel Only)
9 6-Port Steering Valve Solenoid
15 Neutral
22 Work Lights
LV Valve Chest Lock Valve Solenoids
LPG
LP Gas System Relay (Toyota LPG Only)
C/O Engine Cut-Off Relay
