COMECO RT1800 User Manual

10
3.4.3. Programming at LEVEL 3
To access level 3, first set LCK = 0000 from level 2. To enter level 3, press and hold SET and W
for 5 seconds. To switch back to level 1, depress SET and W again.
inP1
Input type selection – sensor type and range
K2
select input range and type
↓ SET
See Appendix 4.1. Input type and range codes. Switching from T/C (voltage) to RTD input type
or vice-versa requires hardware adjustment (see 5.3).
AnL1
Zero adjustment of the analog input for the main output
0
Range: LSPL to USPL
↓ SET
Makes sense only when the selected input type code is among An1 ... An5
See Appendix 4.4. Linear input adjustment
AnH1
Span adjustment of the analog input for the main output
5000
As for AnL1
↓ SET
See Appendix 4.4. Linear input adjustment
dP
Measured value decimal point position (display accuracy)
0000
Sets decimal point position
↓ SET
LSPL
Low limit for measured value and set point
)0
Sets low limit for measured value and set point (narrows input range)
↓ SET
With linear input, sets display value at low limit of the input range (e.g. 2 Bar for 4 mA)
USPL
Higher limit for measured value and set point
40)0
Sets higher limit for measured value and set point (narrows input range)
↓ SET
With linear input, sets display value at high limit of the input range (e.g. 16 Bar for 20 mA)
AnL2
Zero adjustment of the analog input for the second output
0
Range: LSPL to USPL
↓ SET
Makes sense only when the selected input type code is among An1 ... An5
AnH2
Span adjustment of the analog input for the second output
5000
As for AnL2
↓ SET
