3.4.4. Programming at LEVEL 4
To access level 4, first set LCK = 1111 from level 2. To enter level 4, press and hold SET and W
for 5 seconds. To switch back to level 1, depress SET and W again.
The parameters from level 4 grant (1) and deny (0) access to parameters from levels 1, 2, and 3.
Other parameters from level 4 enable (1) and disable (0) certain controller functions.
Parameter symbols ─ SEt0 ... SEt9 ─ appear on the upper (red) display. To browse among
the parameters, use SET.
Each of the four digits of the lower (green) display grants/denies parameter access or enables/disables
function. Thereby, a single parameter (e.g. SEt1) with its four digits controls four parameters or functions.
0 = denies access to parameter / disables function, 1 = grants access to parameter / enables function
SEt1
0
/
1 for
AL2
0
/
1 for
AL1
0
/
1 for
At
0
/
1 for
OUtL
denies/grants access to parameters:
OUtL, At, AL1, AL2
↓ SET
SEt2
0
/
1 for
AnL2,
AnH2
0
/
1 for
LSPL,
USPL
0
/
1 for
AnL1,
AnH1,
dP
0
/
1 for
AL3
denies/grants access to parameters:
AL3, AnL1, AnH1, AnH1, dP,
LSPL, USPL, AnL2, AnH2
↓ SET
SEt3
0
/
1 for
ALt2
0
/
1 for
ALd2
0
/
1 for
ALt1
0
/
1 for
ALd1
denies/grants access to parameters:
ALd1, ALt1, ALd2, ALt2
↓ SET
SEt4
0
/
1 for
CL01,
CH01
0
/
1 for
HYSA
0
/
1 for
ALt3
0
/
1 for
ALd3
denies/grants access to parameters:
ALd3, ALt3, HYSA, CL01, CH01
↓ SET
SEt5
0
/
1 for
idnO,
bAUd
0
/
1 for
rUCY,
WAit,
HYSM
0
/
1 for
CL03,
CH03
0
/
1 for
CL02,
CH02
denies/grants access to parameters:
CL02, CH02, CL03, CH03, rUCY,
WAit, HYSM, idnO, bAUd
↓ SET
