13
SVOS
Set-point shift
0
Range: -1000 to 1000
↓ SET
Unless there is a particular reason, it is recommended to set SVOS = 0
PVOS
Measured-value shift
0
Range: LSPL to USPL
↓ SET
Convenient for calibration
UnIt
Measurement unit for measured value and set point
C
Range: C = °C, F = °F, A = analog input
↓ SET
PVFt
PV filter
1000
Smaller values result in faster reaction, greater values – in better filtering
↓ SET
Adjust the filtering to avoid flickering of input measurement
CASC
(reserved)
↓ SET
OUd
Output action direction
HEAt
HEAt = heating action of output OUT1 , cooL = cooling action of output OUT1
↓ SET
Correspond respectively to direct and reverse action.
The action of OUT2 is always the opposite of that of OUT1
OPAd
Control algorithm
Pid
Range: PID, Fuzzy
↓ SET
PID control incorporates PID Auto-tune and ON/OFF
Hz
Power supply frequency
50
Range: 50 Hz or 60 Hz
↓ SET
over again
Match local mains frequency!
