12
CL02
Calibration of the low limit of the second control output (in case of analog output)
150
Range: LSPL to USPL
↓ SET
CH02
Calibration of the high limit of the second control output (in case of analog output)
3500
Range: 0 to 9999
↓ SET
CL03
Calibration of the low limit of the retransmission output (in case of analog output)
As for CL01
↓ SET
CH03
Calibration of the high limit of the retransmission output (in case of analog output)
As for CH01
↓ SET
rUCY
Full travel time of motor valve (w/o slide-wire position feedback)
00
Range: 0 to 150 s
↓ SET
WAit
WAIT - Waiting for the current segment to end after the time is up in profile control mode
0
0 = no waiting; other values = max. admissible diversion of PV from the set point, at reaching which
the segment may end
↓ SET
SEtA
Additional settings
0000
SETA.1/2/3=1 changes the relays AL1/2/3 action to reverse (NC)
SETA4.4=0 or 1 sets profile program RUN ALARM or END ALARM
↓ SET
idnO
ID number for serial communication
↓ SET
bAUd
Serial communication baud rate
2400
Range: 110 to 9600 bps
↓ SET
To Next Page
